Central Pole Umbrella
The classic market umbrella, engineered for daily retail and hospitality use — smooth crank-and-tilt operation on a Φ48 mm aluminum pole.
Model DC-UP-203
DC-UP-203 — Crank Market Umbrella
Round and square canopies to Φ350 cm with push-button tilt
A dependable all-rounder for patios, cafés and retail programs. The easy-lift crank opens the canopy in seconds and the zinc-alloy push-button tilt angles the shade without releasing the pole.
- Canopy Fabric250 g/m² PU-coated polyester
- UV Protection50+
- PoleΦ48 mm aluminum
- Rib Profile14 × 24 mm — 8 ribs
- OpeningEasy-lift crank
- TiltZinc-alloy push-button tilt
- Canopy ColorsBlack / dark grey / medium grey
- Frame FinishesRock bronze / matte brown / aluminized silver
Dimensions
Size & Geometry
A = canopy span · B = height to canopy top · C = clearance height. Drawing reproduced from our factory catalog.
| Model | Canopy (cm) | A (cm) | B (cm) | C (cm) |
|---|---|---|---|---|
| DC-UP-203-S27 | 270 × 270 | 270 | 210 | 250 |
| DC-UP-203-S30 | 300 × 300 | 300 | — | — |
| DC-UP-203-R30 | Φ300 | 270 | — | — |
| DC-UP-203-R35 | Φ350 | 300 | — | — |
Additional B/C values for the larger sizes available on request — contact us for the full engineering sheet.
Base selection: cross base or resin-fillable base matched to canopy size; resin bases are filled on site for extra ballast.
Also in This Series
DC-UP-224 — Double-Pulley Rope Umbrella
Full aluminum frame with a double-pulley rope system that makes opening and closing remarkably smooth — a step up for premium retail lines.
Model DC-UP-224
DC-UP-224 — Rope System Umbrella
Double-pulley rope, bolt-fixed ribs and reinforced pocket ends
Full aluminum frame with 16×26 mm ribs and a double-pulley rope system. Fabric is 250 g/m² polyester with PU coating, color-fastness grade 5 and UV 50+.
- Canopy Fabric250 g/m² PU polyester, grade-5 fastness
- UV Protection50+
- PoleΦ48 mm aluminum
- Rib Profile16 × 26 mm — 8 ribs
- OpeningDouble-pulley rope system
- FinishPowder coating
| Model | Canopy (cm) | A | B | C |
|---|---|---|---|---|
| DC-UP-224-R27 | Φ270 | 270 | 195 | 240 |
| DC-UP-224-R30 | Φ300 | 300 | 195 | 240 |
| DC-UP-224-S30 | 300 × 300 | 300 | 210 | 245 |
| DC-UP-224-S34 | 300 × 400 | 400 | 210 | 250 |
Engineering
Why Buyers Specify Central Pole Umbrellas
One-Hand Operation
Easy-lift crank (DC-UP-203) or double-pulley rope (DC-UP-224) opens the canopy without effort.
Push-Button Tilt
Zinc-alloy tilt joint angles the shade without releasing the pole — no awkward re-positioning.
PU-Coated 250 g/m² Canopy
Water-repellent polyester with UV 50+ and grade-5 color fastness on the DC-UP-224.
Vented Canopies
Air vents release wind pressure and reduce lift on gusty days.
Three Frame Finishes
Rock bronze, matte brown or aluminized silver powder coating to match any terrace scheme.
Pocket-End Rib Tips
Fabric pockets wrap the rib ends — no exposed metal against the canopy edge.
Also available: Cross bases, resin-fillable bases, protection covers, replacement canopies and spare crank/tilt assemblies — consolidated into your central pole order.
More Shade Options
Explore Other Parasol Lines
Specify Your Central Pole Umbrella
Tell us canopy shape and size, fabric color, frame finish and quantity — we reply with FOB Ningbo pricing within one business day.
