DC-UM-107 Roma — Side-Arm Garden Umbrella
Oval-mast shade with 360° rotation for patios and terraces
The Roma keeps the seating area clear with a side-mounted mast. A 92×68 mm oval aluminum pole carries steel ribs under a 220 g/m² vented canopy, while the two-section pole and stepless lift adjust to every terrace.
- Canopy Fabric220 g/m² polyester with air vent
- Pole92 × 68 mm oval, two-section
- FrameAluminum pole + steel ribs
- Rib Profile14 × 24 mm
- Rotation360° steel rotation
- LiftStepless height adjustment
- Canopy ColorsBlack / dark grey / medium grey
- Frame FinishesRock bronze / matte brown / aluminized silver
Dimensions
Size & Geometry
A = canopy span · B = height to canopy top · C = clearance height. Drawing reproduced from our factory catalog.
| Model | Canopy (cm) | A (cm) | B (cm) | C (cm) |
|---|---|---|---|---|
| DC-UM-107-R27 | Φ300 * | 360 | 210 | 245 |
| DC-UM-107-R30 | Φ330 | 390 | — | 250 |
| DC-UM-107-S27 | 270 × 270 | 330 | — | 245 |
| DC-UM-107-S30 | 300 × 300 | 360 | — | 250 |
* Canopy sizes reproduced as printed in the factory catalog.
Base selection: cross base or resin-fillable base matched to canopy size — we confirm ballast for your wind conditions.
Also in This Series
DC-LUM-102 Banana — Solar LED Garden Umbrella
An arched side-arm design with solar-charged LED lamp beads along the canopy edge — a favorite for evening garden use.
DC-LUM-102 Banana — Arched Arm Umbrella
All-steel frame with pocket ends and solar LED lamp beads
The Banana's arched arm places the canopy overhead with no center pole. An all-steel powder-coated frame, two-section pole and cross base keep it stable, and solar-charged LED beads edge the 200 g/m² vented canopy.
- Canopy Fabric200 g/m² polyester with air vent
- UV Protection50+
- FrameAll steel, powder coated
- PoleΦ48 mm, two-section
- Rib Profile12 × 18 mm
- LightingSolar-charged LED lamp beads
| Model | Canopy (cm) | A | B | C |
|---|---|---|---|---|
| DC-LUM-102-R27 | Φ270 | 330 | 200 | 250 |
| DC-LUM-102-R30 | Φ300 | 360 | 200 | 250 |
| DC-LUM-102-S25 | 250 × 250 | 310 | 200 | 250 |
| DC-LUM-102-S27 | 270 × 270 | 330 | 200 | 250 |
Engineering
Why Buyers Specify the Garden Series
Side-Arm Shade
No center pole in the seating area — chairs and tables stay exactly where you want them.
360° Steel Rotation
Roma's steel rotation collar swings the canopy around the mast to follow the sun.
Solar LED Lamp Beads
Banana: solar-charged beads along the canopy edge light the garden after dark.
Two-Section Poles
Poles split for compact storage and lower freight volume — easier to ship and warehouse.
Vented Canopies
Air vents release wind pressure and reduce lift on gusty days.
Pocket-End Rib Tips
Fabric pockets wrap the rib ends — no exposed metal against the canopy edge.
More Shade Options
Explore Other Parasol Lines
Specify Your Garden Umbrella
Tell us the model, canopy size, fabric color and quantity — we reply with FOB Ningbo pricing within one business day.
